The new RADIUS line of T-Tops introduces curved style in every piece of aluminum. Every RADIUS T-Top features nearly 2" diameter schedule 40 anodized aluminum pipe, fully welded leg and top assemblies, proprietary clamp assemblies for unlimited adjustment, and complete installation hardware kits.
Our RADIUS Pro T-Tops feature full overhead and leg welded handrails, a choice of two leg configurations, and offset mounting bases for a close fit to the console.
Polycarbonate plastics have been used in marine applications for many years. For example, most hatches are manufactured with a metal frame into which is set a translucent polycarbonate. Polycarbonates are also used in everything from bullet proof vehicle
windows to commercial architecture roofing and siding.
Our ATL6 extrusion provides a recess to allow the polycarbonate honeycomb panel to fit nearly flush with the top surface, yet allows for the very different expansion characteristics of aluminum extrusions and polycarbonate plastics without visible gaps or fasteners.
Radius Pro T-Top Sunbrella
Choiceof 5 “Trampoline” colors at no additional charge.
Atlantic Towers manufactures Radius T-Tops with or without a fully welded rocket launcher assembly (gold anodized rod holders are a Special Order option). A variety of accessory kits and fittings make it easy to add flat plates for antennas, navigation lights, deck flood lamps, etc. at any time.
Will the RADIUS Pro T-top fit my center console boat?
KIT24240 Diagonal Brace Option
A few center console boats may provide limited areas to install the standard side brace, or if you have mounted a great deal of heavy equipment on your Trampoline T-Top, such as electronics enclosures, radar, etc, you may want the added stability and support of diagonal sway braces. Fully adjustable and may be secured either on top of the console or on it's forward face. $289
Individual Adjust-O-Launcher Option (AJ30500)
Aluminum rod holders can be mounted anywhere on the perimeter of the "Trampoline" T-top frame. A unique patented design available exclusively from Atlantic Towers, manufactured from all aluminum in natural aluminum anodized finish Adjust-O-Launchers can be pivoted thru 12 positions for unmatched flexibility. $99 each / 4 or more $89 each Gold Anodized finish available for special order. Please call 732-237-8800
55 Watt Deck Lamps Option
55 watt conventional halogen deck flood lamp with replaceable bulb in waterproof housing. Current draw, 4.8 amps each, 9.6 amps a pair at 12 volts. Wire with minimum 14 gauge (always used tinned stranded wire for marine applications). Includes choice of mounting bracket to fit any Atlantic Towers structure. Sold in Pairs
Tower in a Box Arches - Pair MP15000 with KIT54000 Light Mount: $149
Custom Arches - Pair MP150 with KIT54000 Light Mount: $149
KIT22100 Antenna Bracket Option
Antenna Bracket threaded 1"-14 for mounting VHF, GPS and other antennas. Clamps to perimeter of "Trampoline" t-top for fast installation. $109
Anchor/Running Light Option
A two way navigation lamp installed on an anodized aluminum mast with anodized finish to match the "Trampoline" T-top. Functions as all round light with both sides illuminated, or forward steaming light with just forward half illuminated. Custom fitted shoe allows easy bolt-on installation on perimeter of "Trampoline" T-top. Choose 5" height or 18" height. $169
5" Anchor Running Light with LED Head
5" Anchor Running Light with Perko 2 Way Head
18" Anchor Running Light with LED Head
18" Anchor Running Light with Perko 2 Way Head
KIT21000 Pair of Starboard™ Mounting Bars Option
The pair of Starboard™ Mounting Bars allows installation of equipment such as radar by bolting thru top fabric into mounting bars. May also be used to support overhead electronics consoles. $159
Will the "Trampoline" T-top fit my center console boat?
Because of it's adjustability the Basic "Trampoline" T-top (Model TIB5152/55) will fit 90% of center console boats 25' and under. Inboard powered center console boats, where all or part of the console tilts, it may require special hardware or leg configurations.
Basic “Trampoline” T-top Model TIB5152/55
Click image for enlarged view.
Click here for metric dimensions.
Can I install the “Trampoline” T-top myself?
The “Trampoline” T-top was designed for owner installation and is typically no more complicated than installing rod holders or outriggers, just a few more pieces. If you are comfortable with hand tools, the “Trampoline” T-top comes with instructions and all the backing plates and hardware required for a thru bolted installation (If your boat does not allow access for thru bolting, call us and we can explain alternate methods. (Don't want to install the Trampoline T-Top yourself? Check our Services page for professional installers with whom our customers have had a good experience)
How is the “Trampoline” T-top shipped to me? Although the “Trampoline” T-top is not heavy it is too large to go by UPS. We have discounted freight arrangements with several trucking companies, which cover all 48 states and Canada. We can also ship to Alaska, Hawaii and any overseas city, call us for details. The “Trampoline” T-top is packed in a single large cardboard carton (like a mattress) and normally ships to a commercial address (like your business or marina) east of the Mississippi for $125 or less. West of the Mississippi shipping is normally $200 or less. Residential delivery is additional (call for details). (New Jersey shipping addresses or pick ups at our warehouse must pay 7% sales tax)
What happens if my “Trampoline” T-top is damaged in shipping?
Atlantic Towers wants you to enjoy your boat, not spend the season chasing a freight claim. If your “Trampoline” T-top arrives damaged, just refuse the shipment and we will send you a new one at no additional cost to you.
Can I return my “Trampoline” T-top if I decide I don’t want to keep it?
Atlantic will accept the return of any Standard Structure within 30 days of it’s receipt by you. Simply return the Structure in the original packaging in new condition freight pre-paid and we will refund the purchase price less a 10% restocking fee
Is my “Trampoline” T-top guaranteed?
Yes, for 5 years, see the warranty section of our website for details.
How do I get my “Trampoline” T-top? You can purchase a "Trampoline" T-Top directly from Atlantic Towers or our authorized reseller partners around the world.
**NOTE: There is a 10% re-stocking charge for cancelled or returned merchandise**
Due to our dedication to continued product improvement, we reserve the right to make changes without notice.
